High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine

Product Details

Place of Origin: Changzhou, Changzhou

Brand Name: TOM

Certification: ISO9001:2000, ISO14001, OHSAS18001, CE, CO

Model Number: FZX-6A

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Non-fumigation wooden case inserted Iron Shelf, suitable for long time sea delivery

Delivery Time: 30 working days for single machine

Payment Terms: T/T

Supply Ability: 30 sets per month

Get Best Price
Highlight:

High Speed Automatic Capping Machine

,

6 Wheels Automatic Capping Machine

,

6000BPH linear capping machine

Material:
Stainless Steel 304
Capping Speed:
4000-6000BPH
Capping Error:
<0.2%
PLC Control:
Yes
Material:
Stainless Steel 304
Capping Speed:
4000-6000BPH
Capping Error:
<0.2%
PLC Control:
Yes
High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine

Atutomatic High Speed Linear Capping Machine For Various Of Bottle And Caps



Major characteristics:
This capping machine perfectly used for diversified containers in different materials and shapes, such as plastic bottle, glass bottle, metal bottle, etc. caps or bottles changeovers are very quick, easy to be performed. No bottle no capping during the machine cycle. Conveyor, capping machine and bottle clamping belt can separately frequency conversion applicable for allowed various capping range. Meets GMP standard, protecting door may optional which guarantees more safe and environmental.

Technical Parameter:

No. Items Performance
01 Power supply AC220 V; 50Hz (may customized)
02 Power 1.5Kw
03 Production speed 0~4000 bottles/hour
04 Bottle diameter Φ35mm~Φ100mm
05 Cap diameter Φ12mm~Φ50mm
06 Machine Weight 650 Kg
07 Machine Dimension (L×W×H) 2000mm x 850mm x 2050mm

High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 0

Machine details:



Simple and convenient cap adjusting part

High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 1



Screwing cap driving part

High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 2



Capping part is drived by frequency motor

High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 3



Bottle clamp part

High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 4



Applicable products:

High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 5


 Packaging & Shipping
1. the machine is packked by non-fumigation wooden case, and for keeping the wooden case more secure, we inserted the iron support inside wooden case, makes it suitable for long-term sea delivery.
High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 6
High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 7
High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 8

The goods are all loaded at TOM factory by TOM's logistic department.
High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 9
High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 10
High Speed Automatic Capping Machine 6 Wheels Linear Capping Machine 11
