SUS304 1M Round Bottle Feeding Machine For Small Capacity

Product Details

Place of Origin: China

Brand Name: TOM

Certification: CE, ISO,CO

Model Number: JP-J

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: Negotiable

Packaging Details: Sea Worthy Packing

Delivery Time: 10 working days

Payment Terms: L/C, T/T

Supply Ability: 30 sets per month

Get Best Price
Highlight:

Round bottle feeding machine

,

1M bottle feeding machine

,

SUS304 feeding bottle machine

Warranted:
12 Months
Condition:
New
Weight:
450kg
Materials:
SUS304
Diameter:
1 M
Suitable Bottle:
Round
Service:
Online Service
Size:
1700mm×1300mm×1350mm
Warranted:
12 Months
Condition:
New
Weight:
450kg
Materials:
SUS304
Diameter:
1 M
Suitable Bottle:
Round
Service:
Online Service
Size:
1700mm×1300mm×1350mm
SUS304 1M Round Bottle Feeding Machine For Small Capacity

JP-J Diameter 1M Round Bottle Feeding Machine For Small Capacity

Major Characteristics:
The template of this machine adopts stepless speed adjust foe slew, make all the bottles enter into conveyer belt in order under the rotary tangential force, less labor, boost production efficiency.
This machine can be used after electrified. Easing operating, it can be widely used for glass bottles, plastic bottles and polyester bottles for pharmaceutical, agrochemical, food, chemical etc. it is a good choice for small, medium, large factory.


Technical parameters:

Power supply: AC 220V 50 Hz or according client requirements
Power 2kw
Pneumatic source 0.6MPa stable compressed air
suitable Bottle  100-1000ml round bottle

Suitable diameter of bottles :

Ф40mm~Ф100mm
Production capacity 60-100 bpm
Weight 650kg
Machine dimension

1700mm×1300mm×1350mm


Partial Introduce:


Electrical parts:
The electrical part are in top side of machine, can prevent water and material inside it, safety and environmental.

SUS304 1M Round Bottle Feeding Machine For Small Capacity 0





















Packaging & shipping:

SUS304 1M Round Bottle Feeding Machine For Small Capacity 1



warehouse for finished machine:

SUS304 1M Round Bottle Feeding Machine For Small Capacity 2



Loading picture:

SUS304 1M Round Bottle Feeding Machine For Small Capacity 3
