DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml

Product Details

Place of Origin: China

Brand Name: TOM

Certification: CE, ISO,CO

Model Number: DGP-Z-D

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: Negotiable

Packaging Details: Plywood case

Delivery Time: 30 working days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 25 sets per month

Get Best Price
Highlight:

Piston pesticide liquid filling machine

,

DGP-Z-D pesticide liquid filling machine

,

1000ml inline piston filler

Material:
Stainless Stell 304
Filling Volume:
50-1000ml
Speed:
1000-5000 Bottle Per Hour
Filling Type:
By Pistion/Volume
Application:
Both Viscosity And No Viscosity Liquid
Model:
DGP-Z-D
Liquid:
EC, SL, SC, ETC.
Material:
Stainless Stell 304
Filling Volume:
50-1000ml
Speed:
1000-5000 Bottle Per Hour
Filling Type:
By Pistion/Volume
Application:
Both Viscosity And No Viscosity Liquid
Model:
DGP-Z-D
Liquid:
EC, SL, SC, ETC.
DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml
DGP-Z-D PLC Controlled Pesticide Filling Packaging Machine
This is a inline piston filling machine for corrosive liquid and cream. Corrosive liquid filling machine adopts PLC and touch screen control panel for controling materials . It is also suitable for the and high viscosity ,liquid ,semi-liquid .filling of easy volatilization ,easy bubbly liquid strong corrosive liquid for rubber and plastic, Operators adjust and meter figure in the touch screen control panel , also can adjust metering of each filling head .

Major characteristics

This is our newly developed pesticide filling machine. It has reached the international advanced level ,partial has exceeded the similar product . It is also accepoted by the world famous chemical magnate . This is a inline piston filling machine for cream and liquid.It adopts PLC and touch screen control panel for controling materials . It is characterized by accurate measuring ,advanced structure ,stable operating ,low noise ,large adjusting range ,fast filling speed . It is also suitable for the and high viscosity ,liquid ,semi-liquid .filling of easy volatilization ,easy bubbly liquid strong corrosive liquid for rubber and plastic, Operators adjust and meter figure in the touch screen control panel , also can adjust metering of each filling head . The external surface of this machine is made of excellent stainless steel . Good appearance , applied to GMP standard .

Technical parameters



No. Items Performance
01 Power supply AC220V; 50Hz (may customized)
02 Power 1.5 Kw-4.5Kw
03 Air source 0.55Mpa-0.6Mpa clean and stable compressed air
04 Bottle diameter Ф40mm~Ф100mm (may customized)
05 Bottle height 60mm~230mm (may customized)
06 Filling product High viscous, low viscous and non-viscous products
07 Filling range 100ml-1000ml
08 Filling error ≦±2g
09 Number of filling nozzles 4/6/8/10/12/16/20 filling heads
10 Production capacity 1200/1800/2400/3000/3600/4800/6000 bottles/hour
11 Machine weight about 1500Kg
12 Machine dimension (L×W×H)

2000mm×1500mm×2200mm



Durable, scale display, convenient specification adjustment, easy cleaning



DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml 0

DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml 1

Three-way pneumatic valve: our company has 25 years of experience in filling mechanism, and knows that non-professional valve manufacturers are difficult to make valves with good sealing performance. The three-way valve is cast as a whole to prevent leakage.

DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml 2



Our company has a number of solutions for the problems of leakage, wire drawing and foam after filling of materials that users worried

DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml 3



Applicable bottle type



DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml 4

This machine is linear piston type filling machine, with 304 stainless steel environmental protection closed frame, tempered glass door stainless steel edge protection (not frameless ordinary glass), the top left with suction port.

DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml 5

Patent design automatic cylinder cleaning function, can discharge the material completely clean, save the cleaning waste water.

The computer automatically controls the piston cylinder to remove the cylinder quickly.

DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml 6

Threshold protection: the host is equipped with a safety door threshold alarm device. During normal production, open the safety door (around the door), and the host automatically alarms and stops the machine;



DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml 7

An oil-water separator is installed in front of the intake main pipe. When the pressure is too high or too low, the host automatically alarms and stops the machine; (All the above alarms are touch screen display and sound and light alarms at the same time)

DGP-Z-D Fully Automatic Piston Pesticide Liquid Filling Machine 50-1000ml 8
