Bottle Chemical Packaging Machine 50-1000ml Carton Packing Machine

Product Details

Place of Origin: China

Brand Name: TOM

Certification: CE, ISO,CO

Model Number: ZX-01

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: Negotiable

Packaging Details: Plywood case

Delivery Time: 30 working days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 25 sets per month

Get Best Price
Highlight:

Bottle Chemical Packaging Machine

,

50ml Chemical Packaging Machine

,

1000ml Carton Packing Machine

Material:
Stainless Stell 304
Packing Size Size:
50-1000ml Or 1-5L
Speed:
2-12 Carton Per Minute
Carton Size:
L:200-500 W:150-400 H:100-450mm
Application:
Packing Bottle To Carton
Model:
ZX-01
Width Of The Tape:
48/60mm/72mm
Material:
Stainless Stell 304
Packing Size Size:
50-1000ml Or 1-5L
Speed:
2-12 Carton Per Minute
Carton Size:
L:200-500 W:150-400 H:100-450mm
Application:
Packing Bottle To Carton
Model:
ZX-01
Width Of The Tape:
48/60mm/72mm
Bottle Chemical Packaging Machine 50-1000ml Carton Packing Machine

ZX-01 Fully Automtaic PLC Controlled carton packing machine For Bottle

Major Characteristics:

This machine is an intelligent automatic carton packaging machine, it adopts cylinder to push the bottle when the bottle come to the right position, and then adopts vacuum sucker to sucking the bottle, the bottle sucker take the bottles to the forme cartons, and then the sucker release, the loaded carton is sent to the carton sealing, it can avoid hurting the caps with this method. This machine adopts PLC and touch screen controlled with the safety device of alarming and stopping for bottle lacking. Greatly reduce the labor and labor force, it the indispensable machine of automation production line, according to different packaging requirement, can orient the products automatically. Wide application, suitable for many kinds of products.

Main Performance parameter:

Machine type ZX-01
Powder supply 220V/380V 50/60hz 6KW
Suitable size L:200-500 W:150-400 H:100-450mm
Speed 2-12carton/min
Width of the tape 48/60mm/72mm
Air Source 6-7kg
Dimension 2000mm(L)×1200mm(W)×2000mm(H)
Weight 1400KG




Applicable bottle type



Bottle Chemical Packaging Machine 50-1000ml Carton Packing Machine 0

1, according to the user's actual production line capacity, the main machine can be designed for one box, two boxes, three boxes, or customized four boxes, etc. Capacity varies, the number of grippers varies.

2. All actions are centrally controlled by electric control system. High integration, strong control ability, reliable operation;

3. When the host is working, it has the function of interlocking control and protection. All actions are controlled by the programmable controller P LC, photoelectric detection and touch screen operation; When the host is short of bottles, less bottles, short of boxes, less boxes, the host does not work, when the working conditions are met, the host automatically works;

4. All the grippers are imported cylinders of high quality, with firm grip and flexible action

Bottle Chemical Packaging Machine 50-1000ml Carton Packing Machine 1



Bottle Chemical Packaging Machine 50-1000ml Carton Packing Machine 2

The conveyor frame in and out of the box is made of SUS304 stainless steel. The railings on both sides are adjustable and can be applied to different box types. The railings are aluminum profile outsourcing polyethylene material protection rods, and the surface is smooth without burr and will not damage the box.



Bottle Chemical Packaging Machine 50-1000ml Carton Packing Machine 3

There are photoelectric sensors in all parts of the equipment to ensure that no bottles, few bottles, few boxes are not packed, and the work will be carried out after the bottles and boxes are in place



Bottle Chemical Packaging Machine 50-1000ml Carton Packing Machine 4Bottle Chemical Packaging Machine 50-1000ml Carton Packing Machine 5


Jiangsu Tom Group is an enterprise specializing in the production of pesticide / veterinary medicine, fertilizer and chemical intelligent equipment. The factory covers an area of 150 acres and has a construction area of 120,558 square meters. It has 710 employees, 2 doctoral students, 30 master students, and 358 undergraduates. It has obtained ISO9001 quality system. Certification, ISO14001 Environmental Management System Certification, OHSAS18001 Occupational Health and Safety System Certification, CE Certification, Jiangsu Province Specialized Specialized New "Little Giant" Enterprise, Changzhou Specialized Specialized New Small and Medium Enterprise, 125 National Utility Patents and 26 National Inventions patent. Over the past 24 years, after the hard work of Tom people, Tom Group has continued to innovate and develop, keeping pace with the times, providing generations of advanced intelligent packaging equipment for more than 3,300 pesticide / veterinary medicine, fertilizer and chemical companies, and building Industry 4.0 intelligent factories for customers; Provide automated three-dimensional warehouse; create smart factory production data acquisition and execution system (MES) for customers.
